Marine Grade Computer
Marine‑Grade Industrial Computers – engineered by IVC Displays. IP‑Rated, Shock‑Resistant, Built for Offshore and Shipboard Use.
Display specifications
| Item | NP-912-MA (12.1") | NP-919-MA (19") | NP-924-MA (24") |
|---|---|---|---|
| Display type | 12.1" TFT LCD | 19" TFT LCD | 24" TFT LCD |
| Resolution | 1024 × 768 | 1280 × 1024 | 1920 × 1080 |
| Max. color | 16.7 M | 16.2 M | 16.7 M |
| Luminance (cd/m²) | 500 | 350 | 300 |
| Viewing angle (°) | 178 / 178 | 170 / 160 | 178 / 178 |
| Touch type | Projected capacitive touch | ||
| Light transmission | 90 % | ||
| Backlight lifetime | 30,000 hours | ||
System specifications
| CPU | Intel® Core™ i5-8365UE (4C/8T, 1.6 GHz, 15 W TDP) |
|---|---|
| Chipset | SoC |
| System memory | 1 × 260-pin SO-DIMM, 8 GB (up to 32 GB) DDR4 2400 MHz |
| Storage | 1 × 2.5" SATA2 half-size drive bay |
| OS support | Windows 10 IoT 2021 |
| External I/O ports |
4 × USB 2.0 Type A 1 × RS-232 (COM1, 5-pin terminal block) 1 × RS-232/422/485 selectable (default RS-485, COM2, 5-pin terminal block) 1 × DisplayPort 1 × Line-out phone jack 1 × HDMI (with cover) 1 × ESD ground |
| Membrane / keypad control |
Capacitive touch keypad with LED: • Power • Brightness + • Brightness − • Brightness mode swap (DAY / DUSK / NIGHT) • Buzzer |
| Remote power | 1 × 2-pin terminal block connector (remote power switch) |
| Power input connector | 3-pin terminal block connector, DC power input |
Power specifications
| Power supply | Included |
|---|---|
| Power input | 24 V DC |
| Power consumption (NP-912-MA) | 50.88 W |
| Power consumption (NP-919-MA) | 41.8 W |
| Power consumption (NP-924-MA) | 56.6 W |
Mechanical & mounting
| Construction | Aluminum 10 mm bezel and aluminum housing with anti-corrosion coating |
|---|---|
| IP rating | IP65 front panel |
| Mounting | Panel mounting, VESA 75 × 75 |
| Dimensions (W × H × D) |
NP-912-MA: 307 × 266 × 72.5 mm NP-919-MA: 439 × 396 × 76.3 mm NP-924-MA: 609 × 400 × 76.3 mm |
| Net weight |
NP-912-MA: 3.6 kg (7.9 lb) NP-919-MA: 6.5 kg (14.33 lb) NP-924-MA: 7.8 kg (17.19 lb) |
Environmental & certifications
| Operating temperature | 0 °C to 50 °C |
|---|---|
| Storage temperature | −30 °C to 70 °C |
| Relative humidity | 10 % to 90 % @ 40 °C, non-condensing |
| Certifications | CE / FCC Class B / IEC 60945 / Meets IACS E10 / DNV |
Specifications are subject to change without notice. All trademarks are the property of their respective owners.
FAQ – Marine Grade Computers & Displays
What is a marine grade computer?
A marine grade computer is a rugged industrial computer specifically designed for use in
marine environments such as boats, ships, offshore platforms, and naval systems. These
systems are engineered to withstand moisture, salt air, vibration, temperature
fluctuations, and continuous operation.
What makes a computer “marine grade”?
Marine grade computers include corrosion-resistant enclosures, waterproof or
water-resistant protection, vibration and shock resistance, wide operating temperature
ranges, high-brightness sunlight-readable displays, and industrial-grade internal
components. Many systems are also tested to meet marine certifications and environmental
standards.
What applications are marine grade computers used for?
Marine computers are commonly used for vessel navigation systems, ship automation, engine
monitoring, SCADA and HMI applications, radar and sonar systems, offshore drilling
operations, fleet management, surveillance and monitoring systems, and maritime
communication systems.
Are marine grade computers waterproof?
Many marine-grade systems are designed with high IP ratings for protection against water
and dust intrusion. The exact protection level depends on the model and enclosure design.
Can marine computers operate in harsh weather conditions?
Yes. Marine computers are built to perform reliably in challenging environments that
include humidity, salt spray, vibration, heat, cold, and continuous exposure to outdoor
conditions.
Do marine grade computers support touchscreen functionality?
Yes. Many marine panel PCs and displays offer touchscreen functionality, including
resistive and projected capacitive touchscreens. Some models are designed for glove
operation and wet environments.
Are sunlight-readable displays available?
Yes. Marine environments often require high-brightness displays that remain visible in
direct sunlight. High-nit display options are commonly available for bridge systems and
outdoor applications.
What mounting options are available for marine computers?
Common mounting options include panel mount, VESA mount, wall mount, console mount, and
swing arm mount. These options allow flexible installation throughout vessels and marine
control rooms.
What operating systems are supported?
Marine computers may support Windows, Windows IoT, Linux, and embedded operating systems.
Supported platforms depend on the hardware configuration and application requirements.
Are fanless marine computers available?
Yes. Fanless marine computers are popular because they reduce maintenance requirements and
improve reliability in dusty, humid, or corrosive environments.
What industries use marine grade computers?
Industries that commonly use marine computers include commercial shipping, oil and gas,
naval defense, fishing fleets, cruise operations, offshore energy, port operations, marine
research, and transportation and logistics.
Can marine computers integrate with navigation systems?
Yes. Marine computers are often integrated with GPS systems, radar systems, ECDIS
software, AIS systems, NMEA communication networks, and vessel monitoring systems.
What certifications are important for marine computers?
Marine-grade systems may comply with certifications and standards such as IEC 60945, DNV
certification, IACS-E10, CE, and FCC. These certifications help ensure reliability and
compliance in maritime applications.
What display sizes are available?
Marine displays and panel PCs are available in multiple screen sizes ranging from compact
control panels to large bridge displays depending on operational requirements.
Are custom marine computer configurations available?
Yes. Many marine computer systems can be customized with different display sizes,
touchscreen types, processor options, storage capacities, connectivity ports, mounting
configurations, and brightness levels.
Why choose industrial marine computers instead of consumer computers?
Marine-grade computers are specifically engineered for reliability in harsh marine
conditions. Compared to consumer PCs, they offer longer operating life, better
environmental protection, improved durability, 24/7 operational capability, enhanced
vibration resistance, and better system integration for maritime operations.
What connectivity options are available?
Marine computers commonly support Ethernet, USB, HDMI, serial ports, CAN bus, NMEA
interfaces, Wi-Fi, and industrial I/O. Connectivity varies by system model and application
needs.
Can marine computers be used offshore?
Yes. Marine-grade computers are frequently used on offshore drilling platforms, support
vessels, and remote marine installations where durability and reliability are essential.
How long do marine-grade computers typically last?
With proper installation and maintenance, marine-grade industrial computers are designed
for long-term continuous operation and generally outlast standard consumer-grade systems.
How can I request pricing or technical support?
You can contact IVC Displays directly through their contact page for pricing, technical
specifications, custom solutions, and application support.
