NP-9XX-MA Series
Marine Grade Panel PC
Panel PCs for bridges, engine rooms and offshore control stations. Certified to DNV, IEC 60945 and IACS E10, with an anti corrosion aluminum housing and a sunlight readable projected capacitive screen.
DNV
IEC 60945 / IACS E10
IP65
Front panel
12.1 / 19 / 24 in
Screen sizes
Key Features
- Certified to DNV, IEC 60945 and IACS E10
- 10 mm aluminum bezel and housing with anti corrosion coating
- Projected capacitive touch, bright enough for sunlight
- Day, dusk and night brightness keys on a capacitive keypad
- Intel Core i5-8365UE, 8 GB up to 32 GB DDR4
- IP65 front panel, panel mount or VESA 75
Typical Applications
Models
NP-9XX-MA Models and Screen Sizes
Every model shares the platform specifications below. Ask for the size, touch type and configuration you need.
| Model | Screen | Resolution | Brightness |
|---|---|---|---|
| NP-912-MA | 12.1 in | 1024 x 768 | 500 nits |
| NP-919-MA | 19 in | 1280 x 1024 | 350 nits |
| NP-924-MA | 24 in | 1920 x 1080 | 300 nits |
Specifications
NP-9XX-MA Technical Specifications
| CPU | Intel Core i5-8365UE (4C/8T, 1.6 GHz, 15W) |
| Memory | 1 x SO-DIMM, 8 GB up to 32 GB DDR4 2400 MHz |
| Storage | 1 x 2.5 in SATA drive bay |
| Touch | Projected capacitive, 90% light transmission |
| External I/O | 4 x USB 2.0, RS-232 and RS-232/422/485 terminal blocks, DisplayPort, HDMI, line out |
| Keypad | Power, brightness up and down, DAY / DUSK / NIGHT mode, buzzer |
| Power input | 24V DC, power supply included |
| Construction | Aluminum 10 mm bezel and housing, anti corrosion coating |
| IP rating | IP65 front panel |
| Mounting | Panel mount, VESA 75 x 75 |
| Operating temperature | 0°C to 50°C |
| Certifications | CE, FCC Class B, IEC 60945, IACS E10, DNV |
| Operating system | Windows 10 IoT 2021 |
Specifications are subject to change without notice. Confirm your exact configuration with our team.
Where to Buy
Order direct from IVC Displays with a quote, or buy through the distributor your purchasing team already has an approved account with.
Common Questions
Frequently Asked Questions
CE, FCC Class B, IEC 60945, IACS E10 and DNV.
Marine panel PCs are commonly integrated with GPS, radar, ECDIS, AIS, NMEA networks and vessel monitoring systems. Confirm your interfaces with our team.
Industrial Computers
Other Industrial Computers
Get a Quote on the NP-9XX-MA
Tell us the screen size, touch type and configuration you need. Our Saline, MI team will reply with pricing and lead time.
